Changmei Medtech

Guide wire other than intravascular

Intended use: The product is indicated for use throughout the alimentary tract as well as for selective cannulation of the pancreation-biliary system including the common bile duct, pancreatic duct, cystic duct, and right and left hepatic ducts. The Guide Wire other than Intravascular is designed to be used during endoscopic pancreation-biliary as well as gastrointestinal procedures for catheter introduction and exchanges, and to aid in the placement of diagnostic and therapeutic devices.

Features:

  • Anti-twisting and high elastic NiTi core wire provides excellent torsional rigidity and can pass through complex anatomical structures
    successfully;
  • Ultra-smooth PTFE coating is convenient for insertion, and bi-color helix design provides clear judgment of motion;
  • Hydrophilic and radiopaque soft head design ensures smooth movement and accurate positioning under X-ray;
  • Soft and round tip design reduces tissue damage of the patients;
  • Patented soft tip connection technology provides multiple protection, thus it is impossible to break off;
  • Various specifications are available according to clinical requirements, such as stiff guide wire, plastic coated guide wire, zebra guide wire, etc.

Specifications:

Model O.D.(mm/inch) Length***(cm) Characteristics
GW-88-***-A1 0.88/0.035 180,260,450 Big head stiff guide wire
GW-88-***-A2 Flat head stiff guide wire
GW-88-***-B1 260,450 Plastic coated straight guide wire
GW-88-***-B2 Plastic coated curved guide wire
GW-88-***-C1 Straight zebra guide wire
GW-88-***-C2 Curved  zebra guide wire
